TP304 / 304L TP316 / 316L Stainless Steel Tubing Seamless TP347/347H TP321/321H

Categories Stainless Steel Seamless Pipe
Brand Name: zheheng
Model Number: 168mm
Certification: iso9001
Place of Origin: CHINA
MOQ: Negotiable
Price: Negotiable
Payment Terms: L/C, T/T, D/A, D/P
Supply Ability: 50TONS/30DAYS
Delivery Time: 30 DAYS
Packaging Details: In bundles with waterproof material,or wooden crate packing
Material: TP304/304L,TP316/316L,TP347/347H,
Standard: A312
shape: round shape,square
technique: seamless
application: metallurgy
package: woven packing
  • Haven't found right suppliers
  • Our buyer assistants can help you find the most suitable, 100% reliable suppliers from China.
  • And this service is free of charge.
  • we have buyer assistants who speak English, French, Spanish......and we are ready to help you anytime!
  • Submit Buying Request
    • Product Details
    • Company Profile

    TP304 / 304L TP316 / 316L Stainless Steel Tubing Seamless TP347/347H TP321/321H


    Stainless Steel Seamless Pipe sch10 china TP304/304L,TP316/316L,TP347/347H, TP321/321H


    zheheng steel as one of china best quality TP304/304L,TP316/316L,TP347/347H, TP321/321H stainless steel seamless pipe is a hollow long strip of round steel, which is widely used in petroleum, chemical, medical, food, light industry, mechanical instrumentation and other industrial conveying pipelines and mechanical structural components.


    products description :


    Standard : ASTM A312, ASTM A213, ASTM A269, ASTM A511 ASTM A789, ASTM A790 :
    JIS3463, JIS3459, DIN2462, DIN17458, DIN17456
    Grade 304 / 304L / 321 / 321H / 310S / 347H / 2205 / 316 / 316L / 316Ti / 317L
    OD range : 6mm-720mm
    Wall thickness range : 0.5-60mm
    Length max.18000mm or as demand
    Surface finish : Polishing (180#,220#,240#,320#400#,600#), Hairline, acid pickled
    The stainless steel seamless pipe Vickers hardness test is also an indentation test method for measuring very thin metal materials and surface layer hardness. It has the main advantages of Brinell and Rockwell methods, and overcomes their basic shortcomings, but it is not as simple as the Rockwell method. The Vickers method is rarely used in steel pipe standards.

    other terms :

    1.A999/A999M: Each pipe shall be subjected to the nondestructive electric test or the hydrostatic test, the pipe of test to be used shall be at the option of the mfg, unless otherwise specified in the PO.
    2. The Pipe lengths : Unless otherwise agreed upon, all size from NPS 1/8" TO AND INCLUDING nps 8 are available in a length up to 24ft with the permitted range of 15 to 24 ft. Short length are acceptable and the number and min, length shall be agreed upon between mfg and purchaser.
    3. The finished pipe shall be reasonably straight and shall have workmanlike finish, Removal of imperfections by grinding is permitted, provided the W.T are not decreased to the less than the permitted in Section 9 of Specification A999/A999M
    4. Butt Weld End: According to ANSI B 16.25
    5. Pipe Marking: Specified in A999/999M, include "Logo+Standard+SIZE+Heat No.+Lot No.+H.T/E.T/U.T"
    6. Packing: Each Pipe end is protected by Plastic cap. Then packed by Anti-rust steel strip, The outside of the bundle is plastic woven bag, or Plastic film.
    7. Packing Mark: SIZE + STEEL GRADE+ QTY OF PIECE/WEIGHT/METRE.
    8.MTC: BWSS Official Original MTC paper will be supplied for each order.


    In addition, when the bending and torsional strength are the same, the weight is light, so it is also widely used in the manufacture of mechanical parts and engineering structures. Also used to produce a variety of conventional weapons, barrels, shells and so on. Steels that are open at both ends and have a hollow section, and whose length is larger than the circumference of the section, can be called steel pipes. When the length is small compared to the perimeter of the section, it can be called a pipe section or a tubular fitting, which are all in the category of pipe products.



    Applications :
    Foodstuff, gas, metallurgy, biology, electron, chemical, petroleum, boilers, nuclear, energy, construction field, ships building industry, war and electricity industry, boiler heat exchanger, machiner and hardware fields and medical equipment, fertilizer, etc
    stainless steel pipe dimentions
    Dimensions for ASME/ANSI StandardsUnit:mm
    B16.9 B16.28 B36.10
    Nominal pipe Size(NPS)Outside DiameterNominal Wall Thickness
    Sch5sSCH10SSch20Sch30Sch40STDSch80XSSch160XXS
    321.1/442.21.661.652.77-2.973.563.564.854.856.359.70
    401.1/248.31.901.652.77-3.183.683.685.085.087.1410.15
    50260.32.381.652.77-3.183.913.915.545.548.7411.07
    652.1/273.02.882.113.05-4.785.165.167.017.019.5314.02
    our product show :
    Quality TP304 / 304L TP316 / 316L Stainless Steel Tubing Seamless TP347/347H TP321/321H for sale
